Flow Rate Maximum

Eccentric Shaft 5°

180 lph (3 lpm)

180 lph (3 lpm)

180 lph (3 lpm)

Flow Rate Minimum

Eccentric Shaft 5°

1 lph (0.017 lpm)

1 lph (0.017 lpm)

1 lph (0.017 lpm)

Pressure

Temperature of Fluid < 40°C (104°F)

4 bar (58 psi)

4 bar (58 psi)

4 bar (58 psi)

Temperature of Fluid > 40°C (104°F)

4 bar (58 psi)

4 bar (58 psi)

4 bar (58 psi)

Maximum Temperature

Fluid

60°C (140°F)

60°C (140°F)

60°C (140°F)

Suction Lift Dry 330 rpm

Eccentric Shaft 5°

2 – 3 m (6.6 – 9.8 ft)

2 – 3 m (6.6 – 9.8 ft)

2 – 3 m (6.6 – 9.8 ft)

Volume Specifications

Approximated Volume per
Revolution at Free Output

1.2 ml

1.2 ml

1.2 ml

Filling Volume Without Connectors

15 ml

15 ml

15 ml

Connection Specification (Standard)

Connectors

1/4" TC

1/4" TC

1/4" TC

Position of Connectors

Inline

Inline

Inline

Number of Flow Directions

4

4

4

Product Wetted Materials (Standard)

Pump Chamber

PP

PP

PP

Valve Plate

PP

PP

PP

Diaphragms

TPE

TPE

TPE

Valves

EPDM

EPDM

EPDM

O-rings

EPDM

EPDM

EPDM

Certificates/Proofs (Optional)

Elastomere (product wetted)

USP <88> Cl. VI; FDA21CFR177;
BSE/TSE Safe; USP 87/381/661

USP <88> Cl. VI; FDA21CFR177;
BSE/TSE Safe; USP 87/381/661

"USP <88> Cl. VI; FDA21CFR177;
BSE/TSE Safe; USP 87/381/661"

Motor (Standard)

Rated speed

3000 min-1

3000 min-1

3500 min-1

Voltage

100-264 VAC

3 x 230V / 3 x 400V

100-264 VAC

Power

250 W

-

250 W

Pump Dimension with Motor and Housing

Length*

333 mm (13.11")

270 mm (10.63")

333 mm (13.11")

Width*

200 mm (7.87")

114 mm (4.49")

200 mm (7.87")

Height*

217 mm (8.54")

130 mm (5.12")

217 mm (8.54")

Pump Weight with Motor and Housing

9.4 kg (20.9 lb)

5.2 kg (11.5 lb)

9.4 kg (20.9 lb)
