Flow Rate Maximum

Eccentric Shaft 5°

180 lph (3 lpm)

180 lph (3 lpm)

180 lph (3 lpm)

180 lph (3 lpm)

Flow Rate Minimum

Eccentric Shaft 5°

1 lph (0.017 lpm)

1 lph (0.017 lpm)

13 lph (2.166 lpm)

1 lph (0.017 lpm)

Pressure

Temperature of Fluid < 40°C (104°F)

6 bar (87 psi)

6 bar (87 psi)

6 bar (87 psi)

6 bar (87 psi)

Temperature of Fluid > 40°C (104°F)

4 bar (58 psi)

4 bar (58 psi)

4 bar (58 psi)

4 bar (58 psi)

Maximum Temperature

Fluid

80°C (176°F)

80°C (176°F)

80°C (176°F)

80°C (176°F)

CIP

90°C (194°F)

90°C (194°F)

90°C (194°F)

90°C (194°F)

SIP

130°C (266°F)

130°C (266°F)

130°C (266°F)

130°C (266°F)

Autoclave

130°C (266°F)

130°C (266°F)

130°C (266°F)

130°C (266°F)

Ambient Temperature

Minimum

10°C (50°F)

10°C (50°F)

10°C (50°F)

10°C (50°F)

Maximum

30°C (86°F)

30°C (86°F)

40°C (104°F)

30°C (86°F)

Suction Lift Dry at 3000 rpm

Eccentric Shaft 5°

2 - 3 m (6.6 - 9.8 ft)

2 - 3 m (6.6 – 9.8 ft)

2 - 3 m (6.6 – 9.8 ft)

2 - 3 m (6.6 - 9.8 ft)

Volume Specifications

Approximated Volume per Revolution at Free Output

1.2 ml

1.2 ml

1.2 ml

1.2 ml

Filling Volume Without Connectors

15 ml

15 ml

15 ml

15 ml

Connection Specification (Standard)

Connectors

1/4" TC

1/4" TC

1/4" TC

1/4" TC

Position of Connectors

Inline

Inline

Inline

Inline

Number of Flow Directions

4

4

4

4

Product Wetted Materials (Standard)

Pump Housing

SS316L

SS316L

SS316L

SS316L

Valve Plate

SS316L

SS316L

SS316L

SS316L

Diaphragms

TPE

TPE

TPE

TPE

Valves

EPDM

EPDM

EPDM

EPDM

O-rings

EPDM

EPDM

EPDM

EPDM

Certificates/Proofs (Optional)

Elastomere (product wetted)

USP <88> Cl. VI; FDA21CFR177; BSE/TSE Safe

USP <88> Cl. VI; FDA21CFR177; BSE/TSE Safe

USP <88> Cl. VI; FDA21CFR177; BSE/TSE Safe

USP <88> Cl. VI;
FDA21CFR177; BSE/TSE Safe

Stainless Steel Parts (product wetted)

3.1; Surface Roughness; Ferrite Content

3.1; Surface Roughness; Ferrite Content

3.1; Surface Roughness; Ferrite Content

3.1; Surface Roughness; Ferrite Content

ATEX (Motor)

_

_

II 2G Ex db eb IIB T4 Gb

—

ATEX (Coupling)

_

_

II 2G Ex h IIC T4 Gb

—

ATEX (Pump)

_

_

II 2G Ex h IIC T4 Gb X

—

Motor (Standard)

Rated speed

3500 min-1

3000 min-1

3000 min-1

3500 min-1

Voltage

100-264 VAC

3 x 230V / 3 x 400V

400 V

100-264 VAC

Power

250 W

_

0,37 kW

250 W

Pump Dimension with Motor and Housing

Length*

328 mm (12.91")

270 mm (10.63")

460,2 mm (18.12")

328 mm (12.91")

Width*

200 mm (7.87")

114 mm (4.49")

175 mm (6.89")

200 mm (7.87")

Height*

217 mm (8.54")

130 mm (5.12")

310 mm (12.20")

217 mm (8.54")

Pump Weight with Motor and Housing

9,4 kg (20.7 lb)

6,4 kg (14.1 lb)

31,9 kg (70.32 lb)

9,4 kg (20.7 lb)
