Fluid mass flow measurement performance is independent of fluid properties

Flow measurement accuracy of ±1% of reading regardless of changes to flow regime, density, viscosity, and conductivity - eliminating the need to calibrate on different fluids

Disposable drop-in sensor for single-use applications

Eliminates the possibility of cross-contamination and reduces tool downtime for cleaning and sterilization

Multiple fluid properties measured, including temperature, density, and totalized flow

Multiple data points from a single device, mass flow rate, and fluid density allow calculation of volumetric flow rate

Fluid Type

Liquids

Accuracy

±1% of reading

Output

4 to 20 mA; 0 to 5 Vdc, 0 to 10 Vdc, 0 to 1000 Hz

Fluid Pressure

0 to 80 psig

Input Power

24 Vdc ±10%

Sizes Offered

1/8", 1/4”, 3/8", 1/2", 3/4", 1"

Mass Flow Accuracy

±1% of rate for 10% to 100% of full scale rated flow rate
±1% of rate + ZOS for flow rates <10% of full scale rated flow rate

Density Accuracy

Density accuracy ±1%

Temperature*

Ambient: 0°–50°C, Fluid: 2°–40°C
For applications involving temperatures below 10°C, consult factory for special calibration

Operating Pressure

45 psig max. to 80 psig max.

Flow Range**

0.002 to 100 kg/min

Zero Offset Stability (Z.O.S.)

0.0023 to 0.045 kg/min

Supply Voltage

24 Vdc ±10%

Power Consumption

Max 6 W

Programming

Operator parameter configuration through configuration port with a PC

Digital Input/Output Module

Configurable as Frequency or Digital I/O Optional MODBUS over RS485

Frequency Output

0 to 10 KHz proportional to flow rate

Analog Output Module

1x 4-20 mA for mass flow rate or volumetric flow rate 2x 4-20 mA for mass flow rate, volumetric flow rate, temperature or density 3x 4-20 mA for mass flow rate, volumetric flow rate, temperature or density 4x 4-20 mA mass flow rate, volumetric flow rate, temperature and density

Process Connections

1/8", 1/4", 3/8", 1/2", 3/4", or 1" barb connection*
Mini TriClamp, 1" laddish TriClamp

Wetted Material

USP Class VI PEEK (Polyether Ether Ketone)
USP Class VI Silicone
316L Stainless Steel

Programming

Standard 3m; Maximum up to 30m
