Pressure:

Vacuum to 60 psi, 4.14 bar

Temperature:

Polycarbonate: -40°F to 250°F (-40°C to 121°C)

Polysulfone: -40°F to 300°F (-40°C to 149°C)

Gamma irradiation:

Up to 50 kGy irradiation

Autoclave:

Polycarbonate: Up to 250°F (121°C), 30 minutes, up to 10 repetitions. Sterilize uncoupled only.

Polysulfone: Up to 270°F (132°C) for 60 minutes, up to 25 repetitions. Sterilize uncoupled only.

Main component:

Polycarbonate (purple tint)

Polysulfone (amber tint)

Locking Sleeves:

Polysulfone (white)

Thumb latches:

Polycarbonate (white), PVDF (white)

O-rings:

Silicone (clear), platinum-cured; Buna-N (black) - (not USP Class VI or ADCF)

Tubing sizes:

1/8", 1/4" and 3/8" ID (3.22mm, 6.4mm and 9.5mm ID)

Cv~5.5 (79.25) max

Cv values are based on gpm and psi, and Ipm and bar (shown in parentheses).
