Back-to-Back Adapters
Back-to-Back Adapters
.jpg.thumb.1280.1280.png)
.jpg.thumb.1280.1280.png)
.jpg.thumb.1280.1280.png)
SPEC SHEET
OPERATING CONDITIONS (FLUID TRANSFER) |
|
|---|---|
|
Pressure: |
Vacuum to 60 psi, 4.1 bar |
|
Temperature: |
Polycarbonate: -40°F to 250°F (-40°C to 121°C) |
|
Polysulfone: -40°F to 300°F (-40°C to 149°C) |
|
STERILIZATION |
|
|---|---|
|
Gamma irradiation: |
Up to 50kGy irradiation |
|
Autoclave: |
Polycarbonate: Up to 250°F (121°C), 30 minutes, up to 10 repetitions. Sterilize uncoupled only. |
|
Polysulfone: Up to 270°F (132°C) for 60 minutes, up to 25 repetitions. Sterilize uncoupled only. |
|
Materials |
|
|---|---|
|
Main Components: |
Polycarbonate (purple tint) |
|
Polysulfone (amber tint) |
|
|
Thumb latches: |
Polycarbonate (white) |
|
Polysulfone (amber tint) |
|
|
O-rings: |
Silicone (clear), platinum-cured |
CV VALUE |
|
|---|---|
|
Cv~5.5 (79.25) max |
|
|
Cv values are based on gpm and psi, and Ipm and bar (shown in parentheses). |
WARNING: Pressure, temperature, chemicals and operating environment can affect the performance of couplings. It is the customer’s responsibility to test the suitability of Colder products in their own application conditions.
SPEC SHEET
OPERATING CONDITIONS (FLUID TRANSFER) |
|
|---|---|
|
Pressure: |
Vacuum to 60 psi, 4.1 bar |
|
Temperature: |
Polycarbonate: -40°F to 250°F (-40°C to 121°C) |
|
Polysulfone: -40°F to 300°F (-40°C to 149°C) |
|
STERILIZATION |
|
|---|---|
|
Gamma irradiation: |
Up to 50kGy irradiation |
|
Autoclave: |
Polycarbonate: Up to 250°F (121°C), 30 minutes, up to 10 repetitions. Sterilize uncoupled only. |
|
Polysulfone: Up to 270°F (132°C) for 60 minutes, up to 25 repetitions. Sterilize uncoupled only. |
|
Materials |
|
|---|---|
|
Main Components: |
Polycarbonate (purple tint) |
|
Polysulfone (amber tint) |
|
|
Thumb latches: |
Polycarbonate (white) |
|
Polysulfone (amber tint) |
|
|
O-rings: |
Silicone (clear), platinum-cured |
CV VALUE |
|
|---|---|
|
Cv~5.5 (79.25) max |
|
|
Cv values are based on gpm and psi, and Ipm and bar (shown in parentheses). |
WARNING: Pressure, temperature, chemicals and operating environment can affect the performance of couplings. It is the customer’s responsibility to test the suitability of Colder products in their own application conditions.
