AseptiQuik® C
Sterile Connectors
AseptiQuik® C
Sterile Connectors
.png.thumb.1280.1280.png)
.png.thumb.1280.1280.png)
.png.thumb.1280.1280.png)
SPEC SHEETS
AseptiQuik C Assembly Video
Biopharmaceutical manufacturers can make sterile connections with the quality and market availability they expect from the leader in single-use connection technology.
AseptiQuik C Best Practices Video
See how CPC AseptiQuik® Connectors provide quick and easy sterile connections for easier media transfer with less risk of operator error. All without clamps, fixtures or tube welders.
OPERATING CONDITIONS (FLUID TRANSFER) |
|
|---|---|
|
Pressure: |
60 psi, 4.1 bar |
|
Temperature: |
39°F to 104°F (4°C to 40°C) |
|
Typical Flow Rate: |
Cv~14.4 max |
STERILIZATION |
|
|---|---|
|
Gamma: |
Up to 50 kGy irradiation |
|
AutoClave: |
High Temp (HT) Version: Up to 266°F (130°C) for 30 minutes |
CV VALUE |
|---|
|
Cv~14.4 max |
|
Cv values are based on gpm and psi, and Ipm and bar (shown in parentheses). |
MATERIALS |
|
|---|---|
|
Connector: |
Polycarbonate (white), USP Class VI, ADCF |
|
Lock Ring: |
Polycarbonate (blue), USP Class VI, ADCF |
|
Polycarbonate (blue, standard version), USP Class VI, ADCF |
|
|
Pull Tabs: |
Polycarbonate (white, HT version), USP Class VI, ADCF |
|
Caps: |
Polypropylene (clear), USP Class VI, ADCF |
|
Seals: |
Silicone (clear), platinum-cured, USP Class VI, ADCF |
|
Membrane: |
Silicone (clear), platinum-cured, USP Class VI, ADCF |
|
Hydrophobic polyethersulfone (HT version), USP Class VI |
|
OTHER |
|
|---|---|
|
Termination Size: |
1/2" ID hose barb (12.7mm), 3/8" hose barb (9.5mm) and 3/4" sanitary |
WARNING: Pressure, temperature, chemicals and operating environment can affect the performance of couplings. It is the customer’s responsibility to test the suitability of Colder products in their own application conditions.
SPEC SHEETS
AseptiQuik C Assembly Video
Biopharmaceutical manufacturers can make sterile connections with the quality and market availability they expect from the leader in single-use connection technology.
AseptiQuik C Best Practices Video
See how CPC AseptiQuik® Connectors provide quick and easy sterile connections for easier media transfer with less risk of operator error. All without clamps, fixtures or tube welders.
OPERATING CONDITIONS (FLUID TRANSFER) |
|
|---|---|
|
Pressure: |
60 psi, 4.1 bar |
|
Temperature: |
39°F to 104°F (4°C to 40°C) |
|
Typical Flow Rate: |
Cv~14.4 max |
STERILIZATION |
|
|---|---|
|
Gamma: |
Up to 50 kGy irradiation |
|
AutoClave: |
High Temp (HT) Version: Up to 266°F (130°C) for 30 minutes |
CV VALUE |
|---|
|
Cv~14.4 max |
|
Cv values are based on gpm and psi, and Ipm and bar (shown in parentheses). |
MATERIALS |
|
|---|---|
|
Connector: |
Polycarbonate (white), USP Class VI, ADCF |
|
Lock Ring: |
Polycarbonate (blue), USP Class VI, ADCF |
|
Polycarbonate (blue, standard version), USP Class VI, ADCF |
|
|
Pull Tabs: |
Polycarbonate (white, HT version), USP Class VI, ADCF |
|
Caps: |
Polypropylene (clear), USP Class VI, ADCF |
|
Seals: |
Silicone (clear), platinum-cured, USP Class VI, ADCF |
|
Membrane: |
Silicone (clear), platinum-cured, USP Class VI, ADCF |
|
Hydrophobic polyethersulfone (HT version), USP Class VI |
|
OTHER |
|
|---|---|
|
Termination Size: |
1/2" ID hose barb (12.7mm), 3/8" hose barb (9.5mm) and 3/4" sanitary |
WARNING: Pressure, temperature, chemicals and operating environment can affect the performance of couplings. It is the customer’s responsibility to test the suitability of Colder products in their own application conditions.
AseptiQuik C Products
